Thursday, January 12, 2012

Cockpit & Deck layout

Helm Station

Cockpit port side. The bench seat doubles as a pilot berth when the access ladder is folded down.

The sail trim is controlled by dedicated electric winches.

Electric Barient winches and their high/low controls

Access to aft cabin.

Starboard Cockpit bench seat doubles as a second pilot berth.

Access ladder folds down in half to lengthen the bench.

Recessed behind the both port and starboard ladders are the Yankee Jib electric roller furler winches.

Port access ladder stowed to lengthen bench seat.

Port and Starboard Yankee Roller Furling

Starboard side


Starboard Bow

Starboard Quarter

Port Quarter

8ft Caribe with 15 HP
